Tube Packer for high speed packing of plastic or laminate tubes into RSC (flap)-type or lid-type boxes, with or without plastic bag inserts. Ideal for production lines of speeds up to 150 per minute.
- Speed: 150 tubes/minute (speed will vary based on tube diameter and box size)
- Tube types: Extruded and laminate tubes
- Tube diameter:Ø16mm to Ø60mm
- Tube length: 50mm to 250mm (with cap)
- Box type: Lid type and RSC (flap) type boxes with/without plastic bag inserted
- Box size: max 650mm (L) x 450mm (W) x 250mm (H)
Features:
- 6-axis arm to pick and place tubes
- Tubes are placed in a grid before packing in box
- Large 12.1” vertical HMI touchscreen, with IPC based PLC
- Wireless tablet for ease of operation
- Remote diagnostics with modem
- Language options
- High flexibility and reliability
- Total box capacity of 8 boxes (4 empty, 1 being filled, 3 filled)
- Quick and easy changeover
- Exhaustive diagnostic features and alarm system
- Operator login and login history
- Recipes with export/import facility
